Round High Bay
RH743
By True LED USA
RH743 is a versatile LED high bay luminaire featuring adjustable wattage and beam angles, designed for industrial, commercial, and public facilities. Delivering up to 30,000 lumens with an efficiency of 150 lm/W, RH743 incorporates advanced heat dissipation, multiple control options, and durable aluminum alloy housing. With IP54 and IK07 protection, it ensures reliable performance and long lifespan in demanding environments.
Wattage
80W / 100W / 120W / 150W (Selectable)
100W / 120W / 150W / 200W (Selectable)
Lumens
22,500 lm (150W) / 30,000 lm (200W)
Efficacy
-150 lm/W
Color Temperature
4000K / 5000K (Optional)
CRI
80+
Input Voltage
120–277V
Operating Temp
–22°F to +122°F
IP Rating
IP54
Mounting Type
Loop Hanging, Ceiling Mounting
Feature
IK07
Spec Sheet
Document Type
Description
Updated
Download
Spec Sheet
RH743
5/5/2025
Download
Photometry (IES)
Description
Updated
Download
IES Files
5/5/2025
Download
Ordering Information
