Surface Mounted Cleanroom Panel
CR403
By True LED USA
The CR403 Cleanroom LED Panel is a slim, surface-mounted luminaire designed for dust-free and hygienic environments. With selectable wattage options and high efficacy up to 125 lm/W, it provides reliable illumination for laboratories, hospitals, and factories. Its aluminum frame, PMMA light guide plate, and PC diffuser ensure durability and optical performance, while IP65 front protection and IK07 impact resistance guarantee safe operation in demanding cleanroom conditions.
Wattage
2x2: 25W / 30W / 40W (Selectable)
1x4: 25W / 30W / 40W (Selectable)
2x4: 40W / 50W / 60W (Selectable)
Lumens
2,750 – 7,500 lm
Efficacy
110 – 125 lm/W
Color Temperature
3500K / 4000K / 5000K (Selectable)
CRI
80+
Input Voltage
120-277V
Operating Temp
-4°F to +104°F
IP Rating
IP65
Mounting Type
Surface
Feature
IK07
Spec Sheet
Document Type
Description
Updated
Download
Spec Sheet
CR403
5/5/2025
Download
Photometry (IES)
Description
Updated
Download
IES Files
5/5/2025
Download
