Explosion Proof
EXSN1103
By True LED USA
The EX1103 LED Explosion Proof EXIT SIGN is a hazardous location combination unit featuring a 6-inch EXIT lettering legend available in red or green, with alternative wing options (left, right, or both). It includes two fully adjustable LED lighting heads providing up to 2400 lumens each. The unit combines both exit sign and emergency lighting functions in a single robust design, specifically engineered for hazardous environments with Class I Division 2 certification.
Wattage
4W
Lumens
640lm
Efficacy
160lm/W
Color Temperature
CRI
Input Voltage
100-277V
Operating Temp
32°F to 122°F
IP Rating
Mounting Type
Wall / Ceiling / Pendant
Feature
Spec Sheet
Document Type
Description
Updated
Download
Spec Sheet
EXSN1103
5/5/2025
Download
Photometry (IES)
Description
Updated
Download
IES Files
5/5/2025
Download
Ordering Information
